Hydrostatic transmission for ease of operation.
Advanced control system that allows for more options and provides improved diagnostics.
Lightweight design that allows for transport with a truck and trailer.
Electric over hydraulic joystick for greater multifunction capability.
Standard LED Motion/Amber Beacon with ClearSky Smart Fleet Connectivity Hardware.
Maximum Lift Capacity: 6000 lb / 2721.55 kg
Maximum Lift Height: 34 ft 5 in. / 10.49 m
Maximum Reach: 23 ft 2 in. / 7.06 m
| Performance | |
| Drawbar Pull | 12863 lb / 5834.56 kg |
| Frame Leveling | 10 Degrees |
| Lift Capacity at Full Height | 6000 lb / 2721.55 kg |
| Lift Capacity at Max Reach | 1000 lb / 453.59 kg |
| Load Center | 2 ft / 0.61 m |
| Maximum Lift Capacity | 6000 lb / 2721.55 kg |
| Maximum Lift Height | 34 ft 5 in. / 10.49 m |
| Maximum Reach | 23 ft 2 in. / 7.06 m |
| Outriggers or Stabilizers | No |
| Outside Turning Radius | 11 ft 11 in. / 3.63 m |
| Speed - Maximum Lift | 11 sec. |
| Speed - Maximum Lower | 9 sec. |
| Speed - Maximum Telescope In | 10 sec. |
| Speed - Maximum Telescope Out | 10 sec. |
| Speed - Maximum Travel | 15 mph / 24.14 km/h |
| Dimensional Data | |
| Ground Clearance | 1 ft 3 in. / 0.39 m |
| Machine Height | 8 ft 2 in. / 2.48 m |
| Machine Length | 17 ft 6 in. / 5.32 m |
| Machine Width | 7 ft 11 in. / 2.41 m |
| Tire Size | 15-19.5 |
| Wheelbase | 9 ft 2 in. / 2.79 m |
